| 型號 | UP-100 | UP-500 | UP-800 | UP-1200 | UP-650 |
| 圖片 |  |
|
|
 |
 |
| 頻率 | 20KHz | 20KHz | 20KHz | 20KHz | 20-25KHz |
| 最大功率 | 100W | 500W | 800W | 1200W | 650W |
| 振幅頭尺寸 | 1/8" | 1/2" | 1/2" | 3/4" | 1/4" |
| 顯示 | LED | LED | LED | LED | 5" TFT觸控LCD |
| 樣品量 | 100μl~80ml | 50ml~500ml | 50ml~800ml | 50ml~1200ml | 0.5~500ml |
| (選購) 振幅頭 | - | 250μl~80ml(1/8") 10ml~80ml(3/16") |
250μl~80ml(1/8") 10ml~80ml(3/16") |
50ml~80ml(3/16") | 2 / 3 / 6 / 10 / 12mm |
| 功率調節 | 20% / 30% / 60% /100% | Ø5 / Ø5-8 / Ø8-10 / Ø10 | Ø5 / Ø5-8 / Ø8-10 / Ø10 | Ø5 / Ø5-8 / Ø8-10 / Ø10 | 1%~99% |
| 模式 | 連續 / 間歇 / 外接踏板 | 連續 / 間歇 / 外接踏板 | 連續 / 間歇 / 外接踏板 | 連續 / 間歇 / 外接踏板 | 連續 / 間歇 |
| 工作時間 | 3min/time | 8min/time(1/2") 3min/time(1/8" 3/16") |
8min/time(1/2") 3min/time(1/8" 3/16") |
8min/time(1/2") 3min/time(1/8" 3/16") |
8min/time |
| 工作總時間 | 1s~9hr59m59s | 1s~9hr59m59s | 1s~9hr59m59s | 1s~9hr59m59s | 0.1min ~ 999.9min |
| 溫度保護設定 (需安裝溫度偵測線) |
0~99℃ | 0~99℃ | 0~99℃ | 0~99℃ | ≦80℃ |
| 電源 | 110V | 220V | |||
